GRS 3/350 OUT - Opening V max 160 km / h.Container L 580 mm.diam 185mm. PDS with rocket 9.4kg. Max mass parachutable 350kg. Vz 6.4 m / sec. Tps opening 1.5sec. S 72m. 28 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E70. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
