GRS 3/450 OUT - Container L 660 mm diameter x 185 mm.Ouverture Vmax 160km / h. PDS with rocket 13kg. Max mass parachutable 450kg. Vz 6.4 m / sec. Opening time 1.8sec. S 92m. 26 lines. Opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 Extraction provided by parachute rocket (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
