GRS 3/350 OUT - Opening Vmax 250 km / h.Container L 580 mm.diam 185mm. PDS with rocket 10.1kg. Max mass parachutable 350kg. Vz 7.3 m / sec. Tps opening 1.5sec. S 72m. 28 lines. opening distance at 60km / h. 30m / soil. Load on the structure at 4.5 g opening. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is E70 / 4-type. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
