GRS 5/560 SOFT - Container L 680 mm. 210 mm diam. Opening V max 250 km / h.Pds rocket with 12.7 kg. Max parachutable mass 525 kg. Vz 6.4 m / sec. Opening time 2.3 sec. S 110m. 26 lines. Opening distance at 60km / h. 60m / soil. Load on the structure at the opening 2.5G. Strap 5.5 m. supports 50KN. Distance domed 18 m. The hemispherical dome type E115 / 5 and the parachute extraction is carried out by rocket (diam.50mm. 1.5kg weight.) Of thrust 650N / sec
