GRS 3/270 OUT - Opening V max 160 km / h.Container mm.diam L 480 185mm. PDS with rocket 8.6kg. Max mass parachutable 270kg. Vz 6.4m / sec. Tps opening 1.2sec. S 56m. 24 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E60. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
