GRS 4/270 OUT - Opening Vmax 230 km / h.Container mm.diam L 480 185mm. PDS with rocket 8.9kg. Max mass parachutable 270kg. Vz 7.3 m / sec. Tps opening 1.6sec. S 60m. 24 lines. opening distance at 60km / h. 30m / soil. Load on the structure at 4.5 g opening. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is E60 / 4-type. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
