GRS 6/473 SD ULV OF SOFT - Dimension 500 * 250 * 150. Opening Vmax 310km / h. PDS with rocket 10.8kg. Max mass parachutable 473kg. Vz 6.8 m / sec. Tps opening 2.1sec. S 96m. 24 lines. Opening distance of 17 m opening height mini 60km / h. 60m / soil. Load on the structure to 5.0g opening. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 / 5 Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec. German or European approval
