(Code: 20300-S) GRS 5/560 SOFT - Container L 680 mm. 210 mm diam. Opening V max 250 km / h.Pds rocket with 12.7 kg. Max parachutable mass 525 kg. Vz 6.4 m / sec. Opening time 2.3 sec. S 110m. 26 lines. Opening distance at 60km / h. 60m / soil. Load on the structure at the opening 2.5G. Strap 5.5 m. supports 50KN. Distance domed 18 m. The hemispherical dome type E115 / 5 and the parachute extraction is carried out by rocket (diam.50mm. 1.5kg weight.) Of thrust 650N / sec
|
| (Code: 20301-O) GRS 3/450 OUT - Container L 660 mm diameter x 185 mm.Ouverture Vmax 160km / h. PDS with rocket 13kg. Max mass parachutable 450kg. Vz 6.4 m / sec. Opening time 1.8sec. S 92m. 26 lines. Opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 Extraction provided by parachute rocket (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| (Code: 20301-S) GRS 3/450 SOFT - * Opening Max V 160 km / h. PDS with rocket 13kg. Max mass parachutable 450kg. Vz 6.4 m / sec. Tps opening 1.8sec. S 92m. 26 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 Extraction provided by parachute rocket (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
|
(Code: 20302D-O) GRS 6/473 SD DULV OUT – Size 500*250*150. Vmax opening: 310 km/h. Weight with rocket 10.8kg. Parachuting maximum mass 473 kg. Opening time: 2,1 sec. S=96m². 24 shroud lines. Opening distance 17m. Minimum opening height: 60 km/h = 60m/ground. Charge on the opening structure 5,0G. 5.5m strap. Supports 50KN. Distance under the dome: 17m. The hemispherical dome is E90/5. Parachute extraction guaranteed by rocket (diam 0.50 mm weight 1,5 kg) 650N/sec thrust. Certification from both Deutschland or Europe.
|
| (Code: 20302D-S) GRS 6/473 SD ULV OF SOFT - Dimension 500 * 250 * 150. Opening Vmax 310km / h. PDS with rocket 10.8kg. Max mass parachutable 473kg. Vz 6.8 m / sec. Tps opening 2.1sec. S 96m. 24 lines. Opening distance of 17 m opening height mini 60km / h. 60m / soil. Load on the structure to 5.0g opening. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 / 5 Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec. German or European approval
|
| (Code: 20302-O) GRS 6/473 SD OUT- Dimension 500 * 250 * 150. Opening Vmax 321km / h. PDS with rocket 10.8kg. Max mass parachutable 473kg. Vz 6.8 m / sec. Opening time 2.1sec. S 96m. 24 lines. Opening distance of 17 m opening height mini 60km / h. 60m / soil. Load on the structure to 5.0g opening. Strap 5.5 m. supports 50KN. Distance domed 17m. The hemispherical dome type E90 / 5 Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec. approval USA
|
|
(Code: 20304-O) GRS 3/350 OUT - Opening V max 160 km / h.Container L 580 mm.diam 185mm. PDS with rocket 9.4kg. Max mass parachutable 350kg. Vz 6.4 m / sec. Tps opening 1.5sec. S 72m. 28 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E70. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| (Code: 20304-S) GRS 3/350 SOFT - Opening V max 160 km / h.Container L 580 mm.diam 185mm. PDS with rocket 9.4kg. Max mass parachutable 350kg. Vz 6.4 m / sec. Tps opening 1.5sec. S 72m. 28 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5.5 m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E70. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| (Code: 20305-O) GRS 3/350 OUT - Opening Vmax 250 km / h.Container L 580 mm.diam 185mm. PDS with rocket 10.1kg. Max mass parachutable 350kg. Vz 7.3 m / sec. Tps opening 1.5sec. S 72m. 28 lines. opening distance at 60km / h. 30m / soil. Load on the structure at 4.5 g opening. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is E70 / 4-type. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
|
(Code: 20306-O) GRS 3/270 OUT - Opening V max 160 km / h.Container mm.diam L 480 185mm. PDS with rocket 8.6kg. Max mass parachutable 270kg. Vz 6.4m / sec. Tps opening 1.2sec. S 56m. 24 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E60. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| (Code: 20306-S) GRS 3/270 SOFT - Opening V max 160 km / h.Container mm.diam L 480 185mm. PDS with rocket 8.6kg. Max mass parachutable 270kg. Vz 6.4m / sec. Tps opening 1.2sec. S 56m. 24 lines. opening distance at 60km / h. 30m / soil. Load on the structure at the opening 3.5G. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is kind of E60. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| (Code: 20307-O) GRS 4/270 OUT - Opening Vmax 230 km / h.Container mm.diam L 480 185mm. PDS with rocket 8.9kg. Max mass parachutable 270kg. Vz 7.3 m / sec. Tps opening 1.6sec. S 60m. 24 lines. opening distance at 60km / h. 30m / soil. Load on the structure at 4.5 g opening. Strap 5m. supports 50KN. Distance domed 15m. The hemispherical dome is E60 / 4-type. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
|
(Code: 20307-S) GRS 4/270 SOFT - Opening Vmax 230 km / h.Container mm.diam L : 480 185mm. PDS with rocket 8.9kg. Max mass parachutable 270kg. Vz : 7.3 m / sec. Tps opening 1.6sec. S : 60m. 24 lines. opening distance at 60km / h. : 30m / soil. Load on the structure at 4.5 g opening. Strap 5m. supports 50KN. Distance domed : 15m. The hemispherical dome is E60 / 4-type. Extraction parachute rocket provided by (diam.50mm. 1,5kg wt.) Of thrust 650N / sec.
|
| | |
